Original Stepper Motor Driver Controller TB6560

Original Stepper Motor Driver Controller TB6560

Descirption:
100% brand new and high quality
Very easy to use, no instructions, all of use  are marked on the board
Definitely use the new chips imported from  Japan, Toshiba TB6560
With large heat sink to ensure good heat  dissipation
Input signal high-speed optocoupler isolation,  guarantee not losing steps
Semi-flow mode adjustable, semi-flow current  adjustable, not the general design on the market, with a variety of semi-flow  model and semi-flow current setting function
Attenuation model adjusted for all the motors  can be locked when no noise
Ultra-small, the overall size: 62mm * 75mm,  installation of four mechanical positioning hole size: 65mm * 55, hole size f3mm
The form of stud-type connectors and an  optional plug-in

Specification
Rated voltage                 : DC 12V-24V
Maximum current     : 3A-3.5A
Current adjustable (Current Settings) : 0.5A,  1A, 1.5A, 1.8A, 2A.2.5A, 3.5A
Refine your adjustable (Excitation  Mode) : 1,2,8,16
Attenuation adjustable (Decay Mode):
0%             no decay mode
25%          slow decay mode
50%          Normal mode.
100%    fast decay mode

Adjust the decay mode to match the type of  motor impedance, thereby eliminating the jitter noise when the stepper motor is  locked and the motor during exercise.
Automatic half current setting (Torque Settings):
20% ---- no pulse current is reduced to the normal operating current 20%
50% ---- no pulse current is reduced to the normal operating current 50%
75% ---- no pulse current is reduced to the normal operating current 75%
100% --- no pulse current is reduced to the normal operating current 100%
